BATTERY MANAGEMENT
ABM technology (3-stage charging extends battery service life by 50% and provides advance warning for battery replacement)
MAX NUMBER OF BATTERY PACKS
POTENTIAL FREE SWITCH CONTACT
STANDARD FACTORY WARRANTY
- 3-YEAR FACTORY WARRANTY
- - 3 years
- - Parts, electronics and batteries coverage
- - Standard ground shipping
- - Technical support
PACKAGE CONTENTS
- 9SX 2000 VA UPS
- Quick start guide
- RS-232 serial cable
- USB cable
USER INTERFACE
5-button graphical user interface
BATTERY REPLACEMENT
Hot-swappable internal batteries and extended battery modules (EBMs)
TEMPERATURE RANGE
0° to 40°C (32° to 104°F)
COMMUNICATION
- (1) MiniSlot
- (1) USB port
- (1) Serial RS-232 port
- (1) RPO/ROO/Signal input terminal
- (1) mini-terminal block for output relay
EXTENDED SERVICE PLANS
- ADVANCED DEPOT EXCHANGE
- - 5-year depot repair: 9SW5Y-2200UC
- - Expedited parts coverage for 5 years
- - Parts, electronics and UPS batteries coverage
- - Next business day shipping
- - Technical support
-
- 5-YEAR ON-SITE PLAN: WFLN75XX-6009UC
- - On-site parts and labor coverage for years 5
- - Parts, electronics and UPS batteries coverage
- - 24x7 on-site labor coverage, next-day response
- - Next-day shipping
- - Technical support
EXTENDED BATTERY CAPABILITY
OUTPUT NOMINAL VOLTAGE
120V default (100/110/120/125V)
EXPANSION SLOTS
- (1) Mini-Slot (MS) expansion port. Optional connectivity cards may be ordered separately.
- - Gigabit Web/SNMP card part number: NETWORK-M2
- - Modbus card part number: INDGW-M2
- - Relay card part number: RELAY-MS
INPUT FREQUENCY RANGE
60 Hz: 50–70 Hz, 50 Hz: 40–60 Hz
